Storage Area Networks (SAN)

The Vanguard SAN Product line spans a large range of capacities and form factors, and is highly configurable to meet any commercial, industrial or rugged storage area network requirement.

Network Interfaces:	Fibre Channel: 2, 4, 8, 16, 32 Gbps iSCSI: 1 Gbit & 10 Gbit Ethernet
Internal Interfaces:	SATA, SAS, NVME / PCIe
Operating System:	Linux
SNMP v3 Support:	Available
Self Encrypting:	Available
In Line Encryption:	Available
Data Destruction:	10+ Options Available
Capacity:	120 GBytes to 1440 TBytes
RAID Options:	0, 1, 3, & 5
Removable Drives:	2 to 45
Storage Technology:	Solid State or Hard Disk
Cooling Options:	Air Cooled, Conduction Cooled
Temp Ranges:	Commercial, 0 to 70 C Industrial, -45 to + 85 C
EMC / EMI:	MIL-STD-461 Compliant Devices Available

User / Configuration Interface: Fully integrated HTML / Web Page user interface for device configuration and monitoring via an Ethernet connection on-site or from a remote client computer.

PRODUCT SHEET (PDF) >
